Switch|TP-LINK|8x10Base-T / 100Base-TX / 1000Base-T|TL-SG1008P

Name: Switch|TP-LINK|8x10Base-T / 100Base-TX / 1000Base-T|TL-SG1008P
Brand: TP-LINK
SKU: TL-SG1008P
Price: 46.36 EUR
Availability: InStock

Viite TL-SG1008P

Tuotemerkki TP-LINK

46,36 €

Sisältää alv:n

Määrä

Laos

Varastossa: 19 Tuotteet

Kuvaus
Tuotetiedot

Kuvaus

PoE Switches for Your Ultra Convenience
8-Port Gigabit Desktop Switch with 4-Port PoE

Power over Ethernet
4 of the 5 Auto-Negotiation RJ45 ports (Port 1 to Port 4) of the switch support Power over Ethernet (PoE) function. These PoE ports can automatically detect and supply power with those IEEE 802.3af compliant Powered Devices (PDs).

Intelligent Power Management
When total power consumption excels 55W, the intelligent power management will cut the lower priority port power off to ensure the high priority port’s power supply and protect the device from power overload operation.

Sturdy Metal Casing
Sturdy, compact metal casing and shielded RJ45 ports, with desktop, to meet your needs in any environment. Besides, fanless design ensures quiet operation.

8 10/100/1000Mbps RJ45 ports
With four PoE ports, transfers data and power on one single cable
Working with IEEE 802.3af compliant PDs, expands home and office network
802.1p/DSCP QoS enable smooth latency-sensitive traffic
Supports PoE power up to 15.4W for each PoE port
Supports PoE power up to 55W for all PoE ports
Requires no configuration and installation

Tuotetiedot

Tuotemerkki TP-LINK

Viite TL-SG1008P

Varastossa 19 Tuotteet

Lisätiedot

Vendor Homepage: https://www.tp-link.com/uk/service-provider/unmanaged-switch/tl-sg1008p/
Garantija: 60
Category Code: SWI
Unit Box Height: 0.27
Unit Box Length: 0.28
Unit Box Width: 0.23
Units per Shipping Box: 1
Unit Calculated Volume: 0.01739 cubm
Unit Calculated Weight: 0.985 kg
Summary: TP-Link 8-Port Gigabit Desktop PoE Switch with 4-Port. Switch type: Managed. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8. MAC address table: 4000 entries, Switching capacity:
Weight & dimensions (Width): 171 mm
Weight & dimensions (Depth): 98 mm
Weight & dimensions (Height): 27 mm
Packaging data (Package width): 223 mm
Packaging data (Package depth): 280 mm
Packaging data (Package height): 68 mm
Packaging data (Package weight): 900 g
Packaging content (Cables included): AC
Power (Power source): DC/PoE
Packaging data (Package type): Box
Certificates (Compliance certificates): CE/Federal Communications Commission (FCC)/RoHS
Operational conditions (Operating temperature (T-T)): 0 - 40 C
Operational conditions (Storage relative humidity (H-H)): 5 - 90 %
Operational conditions (Storage temperature (T-T)): -40 - 70 C
Sustainability (Sustainability compliance): Yes
Design (Product colour): Grey
Power (AC input frequency): 50/60 Hz
Power (AC input voltage): 100 - 240 V
Power (Power consumption (max)): 75 W
Design (Housing material): Metal
Operational conditions (Operating relative humidity (H-H)): 10 - 90 %
Power (Input current): 1.31 A
Packaging content (User guide): Yes
Design (LED indicators): Yes
Network (Copper ethernet cabling technology): 1000BASE-T/100BASE-TX/10BASE-T
Network (Networking standards): IEEE 802.1p/IEEE 802.3/IEEE 802.3ab/IEEE 802.3af/IEEE 802.3i/IEEE 802.3u/IEEE 802.3x
Power (Number of power supply units): 1
Management features (Switch type): Managed
Ports & interfaces (Basic switching RJ-45 Ethernet ports quantity): 8
Ports & interfaces (Basic switching RJ-45 Ethernet ports type): Gigabit Ethernet (10/100/1000)
Network (10G support): No
Data transmission (Forwarding rate): 11.904 Mpps
Data transmission (Switching capacity): 16 Gbit/s
Design (Rack mounting): No
Power (DC input voltage): 53.5 V
Power (Power supply included): Yes
Power over Ethernet (PoE) (Power over Ethernet (PoE)): Yes
Network (Flow control support): Yes
Ports & interfaces (Power connector): DC-in jack
Network (Cable types supported): Cat3/Cat4/Cat5/Cat5e
Data transmission (MAC address table): 4000 entries
Power over Ethernet (PoE) (Power over Ethernet (PoE) ports quantity): 4
Network (Auto MDI/MDI-X): Yes
Data transmission (Jumbo frames): 16000
Data transmission (Jumbo frames support): Yes
Design (Stackable): No
Network (Auto-negotiation): Yes
Data transmission (Store-and-forward): Yes
Operational conditions (Heat dissipation): 225.75 BTU/h
Performance (Fanless): Yes
Management features (Quality of Service (QoS) support): No
Ports & interfaces (Gigabit Ethernet (copper) ports quantity): 8
Power over Ethernet (PoE) (Total Power over Ethernet (PoE) budget): 64 W
Security (IGMP snooping): Yes
Network (MAC address auto-aging supported): Yes
Network (MAC address auto-learning supported): Yes
Performance (Maximum cable length): 100 m
