| Standard: |
IP |
| Sensor: |
1/2.8 " CMOS |
| Matrix size: |
4 Mpx |
| Resolution: |
2560 × 1440 - 4 Mpx ,
2304 × 1296 - 3 Mpx ,
1920 x 1080 - 1080p ,
1280 x 960 1.3 Mpx ,
1280 x 720 720p |
| Lens: |
5 ... 125 mm |
| View angle: |
54.1 ° ... 3.4 ° |
| Optical zoom: |
x 25 |
| Digital zoom: |
x 16 |
| Range of IR illumination: |
100 m |
| White light LED illuminator range: |
100 m |
| Video output: |
 |
| Preset rotation speed: |
0.1 °/s ... 240 °/s (horizontal) 0.1 °/s ... 200 °/s (vertical) |
| Rotation speed (manual control): |
0.1 °/s ... 200 °/s (horizontal) 0.1 °/s ... 120 °/s (vertical) |
| Horizontal rotation range: |
360 ° - continuous |
| Vertical rotation range: |
-15 ° ... 90 ° |
| RS-485 interface: |
|
| Number of presets: |
300 |
| Horizontal scan: |
 |
| Route settings: |
8 |
| Image compression method: |
Smart H.265+ / H.265 / Smart H.264+ / H.264 / MJPEG |
| Alarm inputs / outputs: |
2 / 1 |
| Audio: |
External microphone input Audio output Audio detection Compliance with the AAC standard |
| Main stream frame rate: |
25 fps @ 4 Mpx |
| Network interface: |
10/100 Base-T (RJ-45) |
| WEB Server: |
Built-in |
| Max. number of on-line users: |
20 |
| ONVIF: |
|
| Memory card slot: |
Micro SD card support up to 512GB |
| Mobile phones support: |
Port no.: 37777 or access by a cloud (P2P) Android: DMSS free application iOS (iPhone): DMSS free application |
| Default IP address: |
192.168.1.108 |
| Default admin user / password: |
admin / -
The administrator password should be set at the first start |
| Web browser access ports: |
80, 37777 |
| PC client access ports: |
37777 |
| Mobile client access ports: |
37777 |
| ONVIF port: |
80 |
| RTSP URL: |
rtsp://admin:hasło@192.168.1.108:554/cam/realmonitor?channel=1&subtype=0 - Main stream
rtsp://admin:hasło@192.168.1.108:554/cam/realmonitor?channel=1&subtype=1 - Sub stream |
| Main features: |
WDR - 120 dB - Wide Dynamic Range 2D NR, 3D NR - Digital Noise Reduction EIS - Electronic Image Stabilization ROI - improve the quality of selected parts of image F-DNR (Defog) - Reduction of image noise caused by precipitation BLC/HLC - Back Light / High Light Compensation
AGC - Automatic Gain Control Privacy zones - max. 24 ICR - Movable InfraRed filter Auto White Balance Thanks to the "Starlight" technology used, the camera only needs very low lighting to obtain a clear color image AcuPick support - technology that uses artificial intelligence on both front-end and back-end to search through massive amounts of video data to quickly locate targets with high precision |
| Intelligent Image Analysis: |
crossing the line (tripwire) intrusion entering the marked area leaving the marked area loitering detection abandoned/missing object fast moving parking detection detection of people gathering face detection - supports 6 types of facial attributes extraction SMD 4.0 - searching for an object classified as: human, motor vehicle - increased detection distance and resistance to false alarms |
| Power supply: |
PoE (802.3at), 12 V DC / 3 A (power adapter not included) |
| Power consumption: |
max. 20 W (12V DC)
max. 23 W (PoE) |
| Housing: |
Speed Dome, Metal |
| Color: |
White + Black |
| Operation temp: |
-40 °C ... 70 °C |
| "Index of Protection": |
IP67 |
| Weight: |
2.4 kg |
| Dimensions: |
270 mm x 160 mm x 160 mm |
| Supported languages: |
Polish, English, Czech, French, Spanish, Dutch, Indonesian (Bahasa), German, Portuguese, Russian, Romanian, Turkish, Ukrainian, Hungarian, Vietnamese, Italian |
| Manufacturer / Brand: |
DAHUA |
| Guarantee: |
5 years |
