1xNumber of displays supported, Maximum weight capacity 10 kg, Maximum screen size 109.2 cm (43"), Suitable for TV Yes, Mounting type Desk, Minimum VESA mount 75 x 75 mm, Maximum VESA mount 100 x 100 mm, Height adjustment Yes, Tilt adjustment Yes, Rotating Yes, Colour Black, Weight 3.5 kg
Range Extender, Data transmission speed 1200 Mbps, Number of antennas 2, Wireless Frequency Range 2.4, 5 GHz (11ac), Wireless Transmit Power 17 dBm, Dimensions 80 x 78 x 77 mm
Launched by Dahua Technology, Dahua WizMind is a full portfolio of solutions composed of project-oriented products including IPC, IVSS,NVR, PTZ, XVR, Thermal and software platform which adopts industry-leading deep learning algorithms. Focusing on customer's requirements, WizMind provides precise, reliable and comprehensive AI solutions for verticals.
Series Overview
With its deep learning algorithms, the WizMind 5 Series camera offers advanced analytical capabilities for both audio and video. It integrates intelligent features such as video metadata, AcuPick, face detection, perimeter protection, and people counting. Powered by the Xinghan Large-Scale AI Models-Vision, the camera outstandingly delivers on its object detection, recognition, and scene adaptation functions. Equipped with AI-ISP imaging technology, it offers excellent night vision performance. The series is designed for durability, being dust-proof, waterproof, and vandal-proof, in compliance with IP67 and IK10 standards, though support for these certifications may vary across models.
Xinghan Large-Scale AI Models-Vision
Xinghan Large-Scale AI Models-Vision seamlessly expands the storage and operational capacity of algorithmic models through the powerful integration of edge AI model algorithms and NPU computing power. Engineered with a lightweight transformer architecture and enhanced by model distillation and quantization techniques, it optimizes the computing power consumption of ViT operators. This enables the system to collaborate on multiple tasks simultaneously through joint inference between small and large models optimized for edge devices.
Self-Learning
Empowered by deep learning technology, the device recognizes different types of targets and their statuses through learning and analyzing target features to detect targets and filter out false alarms.
WizColor Technology
Dahua WizColor Technology seamlessly combines with the powerful AI-ISP, large pixel size sensor and large aperture in cameras. This unique integration enables cameras to effortlessly capture high-quality images with vibrant colors during nighttime scenarios, ensuring fine details are preserved and minimizing motion blur. Unlike traditional self-illuminating cameras, Dahua WizColor Technology maximizes the utilization of weak light sources, such as moonlight and city lights reflected in the sky, delivering captivating full-color images of the entire scene. It also ensures that monitoring distances are not compromised at night due to limited illumination ranges, facilitating full-color image capture even over long distances.
AcuPick
This industry-leading search technology effectively utilizes both front-end and back-end intelligence to help with searching through massive video data to quickly and conveniently locate targets with greater precision.
Protection (IP67, IK10, Wide Voltage)
IP67: The camera passes a series of strict test on dust and soak. It has dustproof function, and the enclosure can work normally after soaking in 1 m deep water for 30 minutes. IK10: The enclosure can stand the punch more than 5 times from a 5 kg hammer falling from a height of 40 cm (Impact energy is 20J). Wide voltage: The camera allows ±30% (for some power supplies) input voltage tolerance (wide voltage range), and it is widely applied to outdoor environment with instable voltage.
Bullet, Wall, White, IP code IP67, Weatherproof Yes, IP security camera, Wired, Placement Outdoor, Maximum operating distance 64 m, Wide Dynamic Range (WDR) Yes, Day, night mode Yes, Optical sensor size 1, 2.7 ", Sensor type CMOS, Identify distance 6 m, Night vision Yes, Total megapixels 5 MP, Built-in microphone Yes, Ethernet LAN Yes,...
Turret, Ceiling, Black, IP security camera, Wired, Placement Indoor & outdoor, Sensor type CMOS, Night vision Yes, Total megapixels 6 MP, Ethernet LAN Yes, Cloud-managed Yes, Power source type DC,PoE, Weight 530 g, 1xNumber of cameras
Eyeball, Black, IP code IP67, IP security camera, Wired, Wide Dynamic Range (WDR) Yes, FOV angle 109 °, Optical sensor size 1, 1.8 ", Sensor type CMOS, Night vision Yes, Total megapixels 6 MP, Built-in microphone Yes, Power source type DC,PoE, Weight 920 g
Bullet, Ceiling, wall, White, IP security camera, Wired, Placement Indoor & outdoor, Sensor type CMOS, Night vision Yes, Total megapixels 8 MP, Ethernet LAN Yes, Cloud-managed Yes, Power source type DC,PoE, Weight 610 g, 1xNumber of cameras
Dome, Ceiling, White, IP code IP67, IP security camera, Wired, Placement Indoor & outdoor, Day, night mode Yes, Pan range 0 - 360 °, Optical sensor size 1, 2.8 ", Sensor type CMOS, Night vision Yes, Night vision distance 30 m, Total megapixels 3 MP, Noise reduction Yes, Built-in microphone Yes, Ethernet LAN Yes, Power source type DC,...
