Valvekaamera 4MP DOME/IArvuti-HDBW2449E-S-IL-0280B DAHUA

Lisainfo

Müüja koduleht

https://www.dahuasecurity.com/ro/products/All-Products/Network-Cameras/WizSense-Series/2-Series/Smart-Dual-Illuminators/IPC-HDBW2449E-S-IL

Garantija

36

Mudel

IPC-HDBW2449E-S-IL-0280B

Category Code

FNC

Unit Box Height

0.115

Unit Box Length

0.138

Unit Box Width

0.137

Units per Shipping Box

20

Unit Calculated Volume

0.002769 cubm

Unit Calculated Weight

0.54 kg

Summary

Dahua Technology WizSense IPC-HDBW2449E-S-IL-0280B. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Ceiling/Wall/Pole, Product colour: White, Form factor: Dome. Angle of rotation: 355 , Lens viewing a

Weight & dimensions (Height)

81 mm

Weight & dimensions (Weight)

350 g

Packaging data (Package weight)

500 g

Performance (Certification)

CE-LVD: EN62368-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU

Operational conditions (Operating temperature (T-T))

-40 - 60 C

Operational conditions (Storage relative humidity (H-H))

0 - 95 %

Operational conditions (Storage temperature (T-T))

-40 - 60 C

System requirements (Mobile operating systems supported)

Android/iOS

Weight & dimensions (Diameter)

109.9 mm

Network (Bluetooth)

No

Network (Ethernet LAN)

Yes

Network (Wi-Fi)

No

Design (Product colour)

White

Power (Power consumption (max))

7.9 W

Power (Power consumption (typical))

2.4 W

Ports & interfaces (Ethernet LAN (RJ-45) ports)

1

Design (Housing material)

Metal

Operational conditions (Operating relative humidity (H-H))

0 - 95 %

Design (Form factor)

Dome

Camera (Camera shutter speed)

1/3 - 1/100000 s

Storage (Compatible memory cards)

MicroSD (TransFlash)

Storage (Maximum memory card size)

256 GB

Power (Power source type)

DC,PoE

Storage (Card reader integrated)

Yes

Audio (Built-in microphone)

Yes

Storage (RAM capacity)

128 MB

Network (Ethernet interface type)

Fast Ethernet

Design (IK code)

IK10

Design (International Protection (IP) code)

IP67

Design (Mounting type)

Ceiling/Wall/Pole

Performance (Connectivity technology)

Wired

Performance (Day/night mode)

Yes

Performance (Placement supported)

Outdoor

Performance (Type)

IP security camera

Camera (Lens viewing angle, diagonal)

120

Camera (Lens viewing angle, horizontal)

101

Camera (Lens viewing angle, vertical)

54

Image sensor (Optical sensor size)

1/2.9 "

Night vision (LED type)

IR/White

Night vision (Night vision)

Yes

Night vision (Night vision distance)

30 m

Video (Frame rate)

30 fps

Video (Maximum resolution)

2688 x 1520 pixels

Video (Noise reduction)

Yes

Video (Noise reduction technology)

3D noise reduction

Video (Total megapixels)

4 MP

Storage (Built-in HDD)

No

Power (DC output voltage)

12

Packaging content (Number of cameras)

1

Image sensor (Sensor type)

CMOS

Lens system (Fixed focal length)

2.8 mm

Camera (Minimum illumination)

0 lx

Video (Back Light Compensation (BLC))

Yes

Video (Highlight Compensation (HLC))

Yes

Image sensor (Progressive scan)

Yes

Video (Gain control type)

Auto/Manual

Camera (Camera shutter type)

Electronic

Video (Region of Interest (ROI) encoding)

Yes

Security (Video motion detection)

Yes

Video (Video compression formats)

H.264/H.264B/H.264H/H.265/M-JPEG

Camera (Angle of rotation)

355

Camera (Pan range)

0 - 355

Camera (Tilt angle range)

0 - 65

Camera (White balance)

Auto/Manual/Natural/Outdoor/Regional custom/Street lamp

Video (Bit rate control)

Constant Bit Rate (CBR)/Variable Bit Rate (VBR)

Video (Supported graphics resolutions)

1280 x 720 (HD 720)/1280 x 960/1920 x 1080 (HD 1080)/2304 x 1296/2560 x 1440/2688 x 1520/352 x 240/352 x 288/640 x 480 (VGA)/704 x 480/704 x 576

Video (Video streaming)

Yes

Network (Supported network protocols)

IPv4 IPv6 HTTP TCP UDP ARP RTP RTSP RTCP RTMP SMTP FTP SFTP DHCP DNS DDNS NTP Multicast ICMP IGMP P2P

Storage (ROM capacity)

128 MB

Management features (Management software)

Smart PSS Lite DSS DMSS DoLynk Care

Management features (Web browser)

Yes

Lens system (Closest focusing distance)

1.1 m

Network (Number of users)

6 user(s)

Security (Mirror)

Yes

Performance (Dynamic range)

120 dB

Lens system (Detect distance)

63.6 m

Lens system (Identify distance)

6.4 m

Lens system (Observe distance)

25.4 m

Lens system (Recognize distance)

12.7 m

Video (Bit rate)

H.264: 32 kbps-6144 kbps H.265: 12 kbps-6144 kbps

Audio (Voice codecs)

G.711a/G.711Mu/G.726/PCM

Network (Networking standards)

IEEE 802.3af

Eriviited

ean13

6923172514202

MPN

1435608
