| Standard: |
IP |
| Resolution: |
2304 x 1296 - 3 Mpx |
| Sensor: |
1/2.8 " CMOS |
| Lens: |
4 mm |
| View angle: |
83 ° |
| Optical zoom: |
 |
| Digital zoom: |
|
| Range of IR illumination: |
30 m |
| White light LED illuminator range: |
30 m |
| Video output: |
|
| Horizontal rotation range: |
0 ° ... 345 ° |
| Vertical rotation range: |
0 ° ... 90 ° |
| RS-485 interface: |
|
| Horizontal scan: |
|
| Route settings: |
 |
| Image compression method: |
H.265 / H.264 / H.264H / H.264B / MJPEG |
| Alarm inputs / outputs: |
|
| Main stream frame rate: |
25 fps - 3 Mpx |
| Memory card slot: |
Micro SD card support up to 256GB |
| Interface: |
Wi-Fi 6 - 2.4 GHz + 5 GHz IEEE 802.11 a/b/g/n/ac/ax, 10/100 Base-T (RJ-45) |
| WEB Server: |
Built-in, NVR compliance |
| ONVIF: |
|
| Audio: |
Microphone built-in Speaker built-in Bi-directional audio streaming support |
| Mobile phones support: |
37777 port Android: DMSS free application iOS (iPhone): DMSS free application |
| Default admin user / password: |
admin / -
The administrator password should be set at the first start |
| Default IP address: |
192.168.1.108 |
| Web browser access ports: |
80, 37777 |
| PC client access ports: |
37777 |
| Mobile client access ports: |
37777 |
| ONVIF port: |
|
| Intelligent Image Analysis: |
Detection of people and vehicles |
| Main features: |
When Smart Dual Light is active, the white light will turn on automatically only when an object is detected in the monitored area, which effectively improves the image quality Active intrusion deterrence works by blinking blue and red light and siren sound or voice prompts Alarm to inform you when an unusual sound occurs Fast pairing with Bluetooth Intelligent Object Tracking D-WDR - Wide Dynamic Range Day/night mode ICR - Movable InfraRed filter Image rotation Motion Detection - max. 4 configurable zones RESET button |
| Power supply: |
12 V DC / 1.15 A |
| Power consumption: |
max. 13.8 W |
| Housing: |
Speed Dome, Plastic |
| Color: |
White |
| "Index of Protection": |
IP66 |
| Operation temp: |
-30 °C ... 55 °C |
| Weight: |
0.40 kg |
| Dimensions: |
Ø 110.0 mm x 140.5 mm (without bracket) |
| Supported languages: |
English |
| Manufacturer / Brand: |
DAHUA |
| Guarantee: |
3 years |
