| Standard: |
IP |
| Resolution: |
2560 x 1440 - 3.7 Mpx |
| Sensor: |
1/3 " Progressive Scan CMOS |
| Lens: |
2.8 mm |
| View angle: |
92 ° |
| Optical zoom: |
 |
| Digital zoom: |
|
| Range of IR illumination: |
30 m |
| White light LED illuminator range: |
|
| Video output: |
|
| Image compression method: |
H.265 / H.264 |
| Alarm inputs / outputs: |
1 / 1 |
| Main stream frame rate: |
25 fps - 3.7 Mpx |
| Memory card slot: |
Micro SD card support up to 256GB |
| Interface: |
Wi-Fi - 2.4 GHz IEEE 802.11 b/g/n/ax, 10/100 Base-T (RJ-45) Fast pairing with Bluetooth |
| WEB Server: |
|
| Max. number of on-line users: |
20 |
| ONVIF: |
|
| Audio: |
Microphone built-in, Speaker built-in, Audio detection, Bi-directional audio streaming support |
| Mobile phones support: |
37777 port Android: DMSS free application iOS (iPhone): DMSS free application |
| Default admin user / password: |
admin / -
The administrator password should be set at the first start |
| Default IP address: |
192.168.1.108 |
| Web browser access ports: |
|
| PC client access ports: |
37777 |
| Mobile client access ports: |
37777 |
| ONVIF port: |
|
| RTSP URL: |
rtsp://admin:hasło@192.168.1.108:554/cam/realmonitor?channel=1&subtype=0 - Main stream
rtsp://admin:hasło@192.168.1.108:554/cam/realmonitor?channel=1&subtype=1 - Sub stream |
| Main features: |
Wi-Fi Module - IEEE 802.11 b/g/n/ac/ax, Image rotation and mirror WDR - Wide Dynamic Range Day/night mode ICR - Movable InfraRed filter Smart motion detection (with recognizing people and vehicles) |
| Power supply: |
PoE, 12 V DC / 1 A |
| Power consumption: |
≤ 2.9 W @ 12 V DC ≤ 5.9 W @ PoE |
| Housing: |
Plastic |
| Color: |
White |
| "Index of Protection": |
IP66 |
| Operation temp: |
-10 °C ... 45 °C |
| Weight: |
0.11 kg |
| Dimensions: |
64 x 100 x 34 mm (without bracket) |
| Supported languages: |
English |
| Manufacturer / Brand: |
DAHUA |
| Guarantee: |
3 years |
