| Standard: |
TCP/IP |
| Sensor: |
1/2.8 " Progressive Scan CMOS |
| Matrix size: |
5 Mpx |
| Resolution: |
2592 x 1944 - 5 Mpx ,
2560 x 1440 - 4 Mpx ,
1920 x 1080 - 1080p
1280 x 720 - 720p |
| Lens: |
5.35 ... 96.3 mm |
| View angle: |
59 ° ... 3.6 ° (manufacturer data) 46 ° ... 3.5 ° (our tests result) |
| Optical zoom: |
x 18 |
| Auto IR illuminator: |
Adaptive adjusting of the IR illuminator power to the lens zoom and outdoor light conditions |
| Range of IR illumination: |
120 m |
| S/N ratio: |
≥ 50 dB (AGC off) |
| Video output: |
 |
| Rotation speed (manual control): |
1 °/s ... 120 °/s (horizontal)
1 °/s ... 60 °/s (vertical) |
| Horizontal rotation range: |
360 ° continuous |
| Vertical rotation range: |
0 ° ... 93 ° |
| RS-485 interface: |
|
| Number of presets: |
255 |
| Horizontal scan: |
 |
| Image compression method: |
H.265 / H.264 |
| Protections: |
Overvoltage |
| Alarm inputs / outputs: |
|
| Network interface: |
10/100 Base-T (RJ-45) |
| Network protocols: |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, SMTP |
| Main stream frame rate: |
20 fps @ 5 Mpx 25 fps @ 4 Mpx |
| WEB Server: |
Built-in |
| ONVIF: |
|
| Mobile phones support: |
Port no.: 80 or access by a cloud (P2P) Android: BitVision free application iOS (iPhone): BitVision free application |
| Default IP address: |
192.168.1.168 |
| Default admin user / password: |
admin / admin |
| Web browser access ports: |
80 |
| ONVIF port: |
8999 |
| RTSP URL: |
rtsp://ip_address/1/h264major - Main stream
rtsp://ip_address/1/h264minor - Sub stream |
| Route settings: |
3 |
| OSD menu: |
preset 95 |
| Main features: |
Intelligent Image Analysis : intrusion, motion detection based on human detection, video tampering D-WDR - Wide Dynamic Range 3D-DNR - Digital Noise Reduction ROI - improve the quality of selected parts of image LDC - lens distortion correction ICR - Movable InfraRed filter BLC - configurable Back Light Compensation Auto White Balance IR illuminator optimization Mirror - Mirror image Privacy zones - max. 3 |
| Power supply: |
12 V DC / 3 A (power adapter included) |
| Power consumption: |
≤ 33 W |
| Housing: |
Speed Dome, Metal |
| Color: |
White + Black |
| "Index of Protection": |
IP66 |
| Operation temp: |
-20 °C ... 60 °C |
| Weight: |
2.34 kg (with bracket) |
| Dimensions: |
340 x 275 x 188 mm (with bracket) |
| Supported languages: |
English, Polish |
| Manufacturer / Brand: |
OMEGA |
| Guarantee: |
2 years |
